HMI DIGITAL 9000 W
Product family features
- High CRI of >90
- UV-Stop (UVS)
- Color temperature of 6,000 K (daylight)
- Extremely bright light of up to 100 lumens/watt
- Hot restart capability
Product family benefits
- Suited for both analog and digital film production
- Robust stems, resulting in less breakage during transport
- Round moly-foil construction that evenly distributes heat and current extends for lamp longevity (6,000-18,000 W)
- Splash-proof carrying case is re-usable and allows lamps to be transported safely (6,000-18,000 W)
Areas of application
- Studio, TV, & Film
- Stage & Theatre
- Professional & High Speed Photography
Safety advice
Because of their high luminance, UV radiation and high internal pressure during operation, HMI lamps may only be operated in enclosed lamp casings specially constructed for the purpose. Mercury is released if the lamp breaks. Special safety precautions must be taken. Information on safety and handling is available on request or can be found in the leaflet included with the lamp or in the operating instructions.
Because of their high luminance, UV radiation and high internal pressure during operation, HMI lamps may only be operated in enclosed lamp casings specially constructed for the purpose. Mercury is released if the lamp breaks. Special safety precautions must be taken. Information on safety and handling is available on request or can be found in the leaflet included with the lamp or in the operating instructions.
High CRI >90
For true-to-life colorsBrightness
Extremely bright light of up to 100 lumens/wattFlicker-free
When used with high-speed electronic ballasts (1000 Hz and higher)UVS (UV stop)
A patented doped UV-Stop quartz outer jacket reduces UV emissions up to 99.9%Technical Data
General Product Information
Product number (Americas)
59941
Product name (Americas)
HMI DIGITAL 9000W 1/CS 1/SKU
Family brand
HMI DIGITAL
Lamp type
SINGLE-END
Global order reference
HMI DIGITAL 9000 W
Electrical Data
Nominal wattage
9000 W
Nominal voltage
160 V
Nominal current
56 A
Photometric Data
Nominal luminous flux
875000 lm
Color temperature
6000 K
Color rendering index Ra
90
Physical Attributes & Dimensions
Lamp base
GX38
Diameter
80.0 mm
Length
380.0 mm
Product weight
940.00 g
Lifetime Data
Nominal lifetime
400 hr
Environmental & Regulatory Information
Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh)
Primary article identifier
4062172001908
Declaration no. in SCIP database
93767d86-c851-4107-80fa-6d9e2ea841f2
Candidate list substance 1
Lead
CAS No. of substance 1
7439-92-1
Safe use instruction
The identification of the Candidate List substance is sufficient to allow safe use of the article.
Packaging information
EAN |
Unit |
Piece |
Dimension l x w x h |
Weight |
Volume |
|---|---|---|---|---|---|
| 4062172001908 |
VS
| 1 | 715mm x 240mm x 240mm | 2226.00g | 41.18dm³ |
